Open Classes (/classes) as admin.
Match types on the form:
match_type | match_value example |
|---|---|
vendor_class | option 60 string |
user_class | option 77 string |
mac_prefix | aa:bb:cc |
Create a class, then:
- Attach DHCP options to the class (same JSON payload shape as subnet options). Default example on the form is code
43with{"hex":"0102"}. - On a subnet, set a pool’s class so only matching clients get that range. Class-specific pools are preferred for matching clients. A PC cannot grab a phone/PXE range by asking for that address.
Matching is evaluated on the DHCP data plane from the class row. Keep class names stable; pools store the class id. Classes stay inside their tenant. You cannot delete a class that a pool still uses.
Readonly sees the list and cannot mutate.
